Описание Ротационные демпферы
Ротационные демпферы ACE позволяют контролировать снижение скорости ротационного или линейного движения, очень просто интегрируются в имеющиеся системы и не требуют проведения техобслуживания. Они часто используются для аккуратного открывания и закрывания крышек небольшого размера, отделений и ящиков, обеспечивая защиту чувствительных компонентов и способствуя повышению качества продукции. Непрерывное движение и ограниченные углы поворота способствуют гармоничным мягким движениям небольших амортизаторов из этой серии. Ротационные демпферы ACE могут использоваться при решении большинства практических задач и могут быть представлены в регулируемых версиях, тормозной момент в которых варьируется от 0,05 Нсм до 40 Нм.
Ротационные демпферы ACE / ACE Controls
|
ACE FDN-47-L "Damping torque 5.5 +/- 0.3 Nm Damping direction left Construction size O 47 mm to 70 mm Rotational speed max. 50 rpm Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx. 80 %… Подробнее... |
|
|
ACE FDN-47-R "Damping torque 5.5 +/- 0.3 Nm Damping direction right Construction size O 47 mm to 70 mm Rotational speed max. 50 rpm Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx. 80… Подробнее... |
|
|
ACE FDN-57-L "Damping torque 8.5 +/- 0.8 Nm Damping direction left Construction size O 47 mm to 70 mm Rotational speed max. 50 rpm Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx. 80 %… Подробнее... |
|
|
ACE FDN-63-R "Damping torque 8.7 +/- 0.8 Nm Damping direction bidirectional Construction size O 47 mm to 70 mm Rotational speed max. 50 rpm Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx.… Подробнее... |
|
|
ACE FDN-70-L "Damping torque 100 Ncm Damping direction right Return Damping Torque 30 Ncm Construction size O 18.5 mm Lifetime 50,000 cycles, even after this time, the dampers still produce over approx. 80 % of their original damping moment. The service life may be… Подробнее... |
|
|
ACE FDN-70-R "Damping torque 2.0 +/- 0.3 Nm Damping direction right Construction size O 47 mm to 70 mm Rotational speed max. 50 rpm Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx. 80… Подробнее... |
|
ACE FDT-47 "Damping torque 4.7 +/- 0.5 Nm Damping direction bidirectional Construction size O 47 mm to 70 mm Rotational speed max. 50 rpm Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx.… Подробнее... |
|
|
ACE FDT-63 "Damping torque 8.7 +/- 0.8 Nm Damping direction bidirectional Construction size O 47 mm to 70 mm Rotational speed max. 50 rpm Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx.… Подробнее... |
|
|
ACE FDT-70 "Damping torque 2.0 +/- 0.3 Nm Damping direction right Construction size O 47 mm to 70 mm Rotational speed max. 50 rpm Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx. 80… Подробнее... |
|
ACE FFD-25FS-L102 "Execution flange assembly, one-sided bearing Damping torque 0.5 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-25FS-L502 "Execution flange assembly, one-sided bearing Damping torque 1.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-25FS-R102 "Execution flange assembly, one-sided bearing Damping torque 0.5 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-25FS-R103 "Execution flange assembly, one-sided bearing Damping torque 0.1 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-25FS-R502 "Execution flange assembly, one-sided bearing Damping torque 1.0 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-25FW-L103 "Execution flange assembly, bi-directional bearing Damping torque 2.0 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-25FW-L153 "Execution flange assembly, bi-directional bearing Damping torque 2.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-25FW-R103 "Execution standard assembly, bi-directional bearing Damping torque 1.5 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-25FW-R153 "Execution standard assembly, bi-directional bearing Damping torque 2.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-25FW-R203 "Execution standard assembly, bi-directional bearing Damping torque 3.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-25SS-L103 "Execution standard assembly, one-sided bearing Damping torque 0.1 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-25SS-L502 "Execution standard assembly, one-sided bearing Damping torque 1.0 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-25SS-R103 "Damping torque 200 +/- 40 Ncm Damping direction left Construction size O 40 mm Rotational speed max. 50 rpm Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx. 80 % of their… Подробнее... |
|
|
ACE FFD-25SS-R502 "Damping torque 50 +/- 10 Ncm Damping direction left Construction size O 40 mm Rotational speed max. 50 rpm Lifetime 50,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers still produce over approx. 80 % of their… Подробнее... |
|
|
ACE FFD-25SW-L103 "Execution standard assembly, bi-directional bearing Damping torque 2.0 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-25SW-L153 "Execution standard assembly, bi-directional bearing Damping torque 2.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-25SW-L203 "Execution standard assembly, bi-directional bearing Damping torque 3.0 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-25SW-R103 "Execution standard assembly, bi-directional bearing Damping torque 1.5 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-25SW-R153 "Execution flange assembly, one-sided bearing Damping torque 1.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-25SW-R203 "Execution standard assembly, bi-directional bearing Damping torque 1.0 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-28FS-L102 "Execution flange assembly, one-sided bearing Damping torque 0.1 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-28FS-L103 "Execution flange assembly, one-sided bearing Damping torque 1.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-28FS-L502 "Execution flange assembly, one-sided bearing Damping torque 1.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-28FS-R102 "Execution flange assembly, one-sided bearing Damping torque 0.1 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-28FS-R103 "Execution flange assembly, one-sided bearing Damping torque 0.1 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-28FS-R502 "Execution flange assembly, one-sided bearing Damping torque 0.5 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
|
|
ACE FFD-28FW-L103 "Execution flange assembly, bi-directional bearing Damping torque 1.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-28FW-L153 "Execution flange assembly, bi-directional bearing Damping torque 1.5 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-28FW-L203 "Execution flange assembly, bi-directional bearing Damping torque 1.5 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-28FW-R103 "Execution flange assembly, bi-directional bearing Damping torque 1.0 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-28FW-R203 "Execution flange assembly, bi-directional bearing Damping torque 2.0 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-28SS-L102 "Execution standard assembly, one-sided bearing Damping torque 0.1 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-28SS-L103 "Execution standard assembly, one-sided bearing Damping torque 0.1 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-28SS-L502 "Execution standard assembly, one-sided bearing Damping torque 1.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-28SS-R102 "Execution standard assembly, one-sided bearing Damping torque 0.1 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-28SS-R502 "Execution standard assembly, one-sided bearing Damping torque 0.5 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the… Подробнее... |
|
|
ACE FFD-28SW-L153 "Execution standard assembly, bi-directional bearing Damping torque 2.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-28SW-L203 "Execution standard assembly, bi-directional bearing Damping torque 2.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-28SW-R153 "Execution standard assembly, bi-directional bearing Damping torque 1.5 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-28SW-R203 "Execution standard assembly, bi-directional bearing Damping torque 1.5 Nm Damping direction right Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time,… Подробнее... |
|
|
ACE FFD-30FS-L103 "Execution flange assembly, one-sided bearing Damping torque 1.0 Nm Damping direction left Construction size O 25 mm to 30 mm Rotational speed max. 30 rpm Lifetime 30,000 cycles (1 cycle = 360° left-hand, 360° right-hand). Even after this time, the dampers… Подробнее... |
